| YACHT NAME: |
Partida |
| BRAND AND MODEL: |
Nordhavn 46 |
| TYPE: |
Long range pilothouse trawler yacht |
| LOCATION: |
Cruising Mexico/California |
| MODEL YEAR: |
1991 |
| HULL NUMBER: |
25 |
| HULL COLOR: |
White painted hull – blue stripe and black bottom paint |
| REGISTRY: |
United States Coast Guard documented 1050550 |
| DESIGNER: |
Jeff Leishman |
| BUILDER: |
P.A.E./South Coast – Taipei, Taiwan |
| HULL MATERIAL: |
Solid fiberglass |
| DISPLACEMENT: |
67,000 LBS. | 30.39 MT |
| BALLAST: |
6,600 LBS. | 2.99 MT |
| RANGE: |
Cruising range 3,000 NM @ 7.0 knots |
| SPEED: |
Cruise 7.0 knots. Max speed 8.5 knots. |
| LOA: |
45’9″ | 13.94 M |
| LWL: |
38′ 4″ | 11.68 M |
| BEAM: |
15’5″ | 4.7 M |
| DRAFT: |
5’6″ | 1.68 M |
| AIR DRAFT: |
Approximately 34′-5″| 10.5 M with mast up. Note: Mast has hinge on base, air draft profile can be lowered to 18′ | 5.49 M |
| AB RATIO |
2.3:1 |
| DL RATIO |
383 |
| CP – PRISMATIC COEFFICIENT |
0.63 |
| ENGINE |
Lugger L-6414 D 143HP (Main hours: ~7000 December, 2021) |
| PROPELLER / SHAFT |
Four blade 30 LH 22 bronze propeller | 2″ diameter shaft |
| MAIN EXHAUST: |
Dry stack, keel cooled |
| WING ENGINE: |
Yanmar 3GM 30FV -27 HP (Wing hours: ~300 December 2021 – no meter) |
| THRUSTERS: |
Wesmar electric bow and stern thruster |
| STABILIZATION: |
Naiad active fin stabilization (model number 254) |
| ELECTRICAL: |
60 Hertz – US style | Solar panels on pilothouse roof |
| SHORE POWER: |
50 amp for house and 50 amp for air conditioning |
| GENERATOR: |
Northern Lights 12 kW (Generator hours: ~ 9,300 December 2021) |
| INVERTER/CHARGER: |
Magnum Energy ME 2512 – inverter/charger | Lewco battery charger |
| BATTERIES: |
Lifeline AGM |
| INTERIOR LIGHTING: |
LED |
| CLIMATE CONTROL: |
Cruisair air conditioning – (3) units:16,000 BTU’s saloon, 12,000 BTU’s pilot house, 12,000 BTU’s staterooms |
| WATERMAKER |
FCI Aquamiser Model A516S – 500 gallons per day |
| MACHINERY EQUIPMENT: |
FloScan fuel sentry | Viqua VT1-DWS ultraviolet water purifier/filter |
| WINDLASS: |
Maxwell VWC 3500 electric windlass |
| GROUND TACKLE: |
Bruce 50 KG plow primary with 400′ chain | Delta plow secondary with chain |
| MAST: |
Aluminum painted mast with two flopper stopper outriggers |
| CRANE: |
Marquipt 1,000 pound |
| TENDER AND OUTBOARD: |
10′-6″ AB Mares RIB with Honda 20 HP outboard |
| NAV/COM BRANDS: |
ICOM | Furuno | Simrad | Orion |
| ENTERTAINMENT: |
Samsung 5500 series 32″ TV | Zvox AV157 soundbar |Sony Samsung 4000 series 26″ TV | Sony Blu-ray Player |Fusion MS-CD600 stereo with Bluetooth and Sirius |
| STATEROOMS: |
(2) staterooms: Owner aft, Guest cabin forward |
| BEDDING: |
Custom mattress in owner stateroom |
| HEADS: |
Jabsco electric freshwater flush in owner | Groco K manual seawater flush in guest |
| SHOWERS: |
Stand up shower in owner head with curtain | Stand up shower in guest head with curtain |
| GALLEY: |
Force 10 – (3) burner propane stove and oven | Sea Freeze stand up refrigerator/freezer | GE Advantium convection oven | Seagull IV water filter |Cold plate freezer in owner stateroom |
| INTERIOR WOOD: |
Teak with gloss finish on trim |
| INTERIOR COUNTERS: |
Quartz counters in galley and heads; cork counters in pilothouse, saloon, and staterooms |
| INTERIOR UPHOLSTERY: |
Ultraleather |
| INTERIOR FLOORING: |
Teak and spruce hardwood |
| BILGE PUMPS: |
(1) Jabsco electric, (1) Edson manual |
| TANKAGE: (approx.) |
|
| FUEL: |
1,000 gallons | 3,785 L (4 mild steel tanks) |
| HOLDING BLACK: |
50 gallons | 189 L (2 fiberglass tanks) |
| FRESH WATER: |
280 gallons | 1,060 L (2 stainless steel tanks) |
| DECK GEAR: |
13′ pedal drive Old Town Predator kayak | 10′ pedal drive Native Watercraft Slayer kayak |
| SAFETY: |
Fireboy fire suppression in engine room | (2) ACR EPIRB | (2) West Marine auto inflatable life jackets | Switlik 6-person liferaft in cannister | Storm plates for saloon windows |
| SPARES: |
All spare parts will remain on vessel |
| PHOTO DATE: |
Most photos taken November, 2021 |
|
Note: All information is believed accurate but should be verified. |
